Straight Knife GrindersGrinding tolerance +/- 0,005 mm/m
Göckel America offers generations of experience in the machine knife sharpening and manufacturing industries. Our inventory of grinding supplies, application assistance, and network of users is available to all our customers. All of our equipment is manufactured to the highest standards of quality, yielding longevity and accuracy for decades of production.
Machine Construction
Machine Bed
Welded construction in cell design. Precision machined for the highest accuracy.
Guide Ways
Three systems available depending upon model:
- Hardened and ground way bands
- Bolted on hardened and ground box ways
- High precision linear ways
Machine Tables
- (PL) Flat fixed table
- (EL) Electromagnetic rotating table
- (ELD) Double electromagnetic rotating tables
Grinding Carriage
Cast iron construction with precision guide rolls, support guiding and tapered gib.
Down Feed System
For grinding tool, ball screw and nut system. Impulse feed, rapid positioning, and digital display. Many option of programmability are available.
Grinding Motor
Strong hollow shaft and high precision bearings, tiltable for cross and radial grinding.
Grinding Tools
Ring type grinding wheel, segmental head, diamond or CBN grinding wheels.
Diameter and size depend upon the model and application. Please view our grinding supplies list for more details.
Traverse Drive
Variable Servo or AC inverter drives
Coolant System
Large external coolant tank and pumps supply coolant through the hollow motor shaft and from the sides. Many filter options are available.
Electrical Cabinet
Separate installed cabinet using the latest technique in controls.
Options and Steps of Automation
- Magnetic quickchange device for grinding wheel
- Pendulum and creep feed grinding
- Electrical demag control for work-table
- NC and CNC controls
- Steplessly variable grinding motor
- Multiple chuck or two work station arrangements
- Automatic sizing unit with wheel wear compensation
- Grinding vapor extraction and enclosures
- Programable controls for automatic grinding cycles
- Special fixturing, handling systems and robotic automation
