Vertical Long Table Surface Grinders

Vertical Long-Table Surface Grinding Machines Type-G

Grinding Lengths: 1700 ~ 15000mm
Grinding Widths: 300 ~ 1100mm
Grinding Motor: 40 ~ 350kw (50 ~ 470hp)
Segment head, ring wheel or cup wheel

Basic Machine Construction


Machine Base

Welded construction, cell design, thermally relieved and vibration dampened. Smooth interior for good coolant drainage and cleaning. Through hardened precision ground ways.

Grinding Carriage

Heavy duty cast iron construction for best load distribution and smooth operation. Pre loaded roll system for horizontal movement and adjustable, long flat guide ways for vertical movement. Ball screw system with hydraulic weight compensation.

Machine Table

Cast iron or electromagnetic chucks with steplessly variable speeds. One or two axis tilting, hollow grind or face grinding. Variable magnetic controller.

Coolant System

Strong coolant pumps, large tank and many option for coolant filtration.
